Snorkel MHP13AT 12m Telescopic Trailer Mounted Boom
$64,900.00 Inc. GST
$59,000.00 Ex. GST
The Snorkel MHP13AT is a heavy-duty trailer-mounted boom lift, offering a 12.9m working height and 6.4m horizontal outreach. With a two-person platform, automatic levelling, and both electric and diesel options, it’s ideal for elevated work across a variety of indoor and outdoor job sites.
The Snorkel MHP13AT Telescopic Boom Lift is built for safe, stable access at height with the convenience of a towable frame. Delivering a working height of 12.9 metres and horizontal outreach of 6.4 metres, this model provides robust performance in maintenance, tree work, signage, and light construction tasks.
Designed with user safety and mobility in mind, the MHP13AT features a durable two-man steel platform, hydraulic stabilisers, and 540° non-continuous rotation for broad reach. Its compact stowed dimensions and articulated boom ensure accessibility in tight or constrained areas. This trailer-mounted boom lift is available in petrol, diesel, or bi-energy configurations, catering to both rugged outdoor and low-emission environments.
With user-friendly interlocks, proportional controls, and reliable performance, the Snorkel MHP13AT stands out as a versatile option for hire or project deployment where dependable access equipment is a must.
Key Features
This trailer-mounted boom lift reaches a working height of 12.9 metres with 6.4 metres of outreach.
It includes a heavy-duty two-person steel platform measuring 1.15m x 0.7m.
Equipped with automatic levelling stabilisers for rapid and secure setup.
Offers 540° non-continuous turntable rotation to improve accessibility and reach.
Hydraulic outriggers, disc brakes, and a robust jockey wheel enhance site mobility and safety.
The platform includes foot switches, overload protection, and easy-to-use safety interlocks.
Designed with a compact footprint and retractable outriggers for easier transportation and positioning.
Available in petrol, diesel, or bi-energy power options to suit varied site requirements.
Petrol engine standard (Honda) with optional diesel or bi-energy (engine & battery) configurations.
Specs
- Max. Working Height: 12.9 m
- Max. Platform Height: 10.9 m
- Max. Working Outreach: 6.4 m
- Platform Size: 1.15 m x 0.7 m
- Platform Capacity: 215 kg
- Gross Weight: 1,460 kg
- Levelling System: Automatic
- Turntable Rotation: 540° non-continuous
- Tyres: 185 R14 102/100P
- Brakes: Hydraulic over-run, non-free-reversing
- Trailer Tongue Weight: 80 kg
- Overall Width (Stowed): 1.6 m
- Overall Width (Extended): 3.6 m
- Overall Length: 4.9 m
- Transport Length: 2.0 m
- Max. Wind Speed: 12.5 m/s
- Insulation Rating: None
