JLG Toucan T10E-L 11m Vertical Mast Boom
$53,130.00 Inc. GST
$48,300.00 Ex. GST
The JLG Toucan 10E-L is a compact electric mast boom lift delivering an 8.10m platform height and 3.38m outreach. Designed for indoor access in confined areas, it combines precise manoeuvrability with zero emissions and ultra-quiet operation—ideal for warehouses, maintenance, and facility environments.
The JLG Toucan 10E-L is purpose-built for indoor vertical access where space is limited and noise must be minimised. With a total working height of 10.10 metres and 6.51 metres of up-and-over clearance, it enables operators to reach obstructed areas without repositioning the base.
Its mast-style design, compact 990mm width, and non-marking tyres allow it to navigate tight aisles and standard doorways with ease. The 1.6 metre articulating jib and 345° mast rotation enable flexible positioning, making it a practical alternative to a knuckle boom lift in low-height applications.
Fully electric with dual AC drive motors and AGM batteries, the Toucan 10E-L offers responsive performance and extended runtime. Integrated features such as proportional joystick control, on-board diagnostics, passive pothole protection, and a steel platform with slide-bar entry enhance safety and user comfort. It’s the ideal choice for high-reach tasks in clean, quiet, or sensitive indoor environments.
Key Features
The 1.6 metre articulating jib and 345° mast rotation deliver enhanced manoeuvrability for reaching around obstacles.
A 0.90 m x 0.70 m steel platform with rear slide-bar entry provides secure working space for up to two operators.
Dual brushless AC drive motors offer smooth torque and efficient energy usage with zero emissions.
Full proportional joystick controls ensure accurate mast and jib positioning during operation.
An auto power-save mode and low charge cut-out help optimise battery life and energy usage.
Heavy-duty steel mast construction provides smooth vertical lift and long-lasting durability.
On-board diagnostics and integral display simplify troubleshooting and service.
Safety systems include tilt alarm, load sensing, pothole protection, and manual descent.
24V DC system powered by 4 x 260 Ah AGM batteries with integrated charger and dual AC electric drive motors
Specs
- Working Height: 10.10 m
- Platform Height: 8.10 m
- Working Outreach: 3.38 m
- Up and Over Height: 6.51 m
- Platform Size: 0.90 m x 0.70 m
- Jib Length: 1.60 m
- Jib Articulation: 126° (+65° / -61°)
- Swing: 345° (non-continuous)
- Turning Radius (Inside): 0.55 m
- Turning Radius (Outside): 1.99 m
- Drive Speed (Lowered): 5.5 km/h
- Drive Speed (Elevated): 0.75 km/h
- Gradeability: 25%
- Tailswing: 12 cm
- Stowed Height: 1.99 m
- Overall Length: 2.82 m
- Overall Width: 0.99 m
- Wheelbase: 1.20 m
- Ground Clearance: 10 cm
- Platform Capacity: 200 kg (2 persons indoor, 1 person outdoor)
- Machine Weight: 2,600 kg
Purchasing from Swift Equipment will ensure you can take advantage of JLG’s “1 & 5” warranty.
JLG provide warranty coverage on this product for one year and covers all specified major structural components for five years. Due to continuous product improvements, the manufacturer reserves the right to make specification and/or equipment changes without prior notification. This machine meets or exceeds AS/NZS 1418.10 2011 as originally manufactured for intended applications.
