JLG 460SJ HC3 46ft Telescopic Boom Lift (High Capacity)
$130,020.00 Inc. GST
$118,200.00 Ex. GST
The JLG 460SJ HC3 is a telescopic boom lift designed for reaching high and out from the base machine. It has a maximum platform height of 14.05 m, up to 12 m of horizontal outreach and a maximum platform capacity of 454 kg. Its higher-capacity platform makes it useful when several workers and their tools need to be taken to the work area.
The 460SJ HC3 is designed to give you both height and reach. Its telescopic boom can extend outwards, allowing operators to reach areas that are not directly above the machine.
The platform can carry up to 454 kg, and JLG describes it as being able to accommodate up to three workers and their tools. This is useful on jobs where bringing materials and equipment up with the crew saves repeated trips to ground level.
The 460SJ HC3 is suited to construction, structural work, building maintenance, industrial work and installation. It is particularly useful when the working area is not directly above the machine and you need to reach over or around an obstruction.
Key Features:
- Load Sensing System: Automatically monitors platform capacity to help maintain safe operation and prevent overloading.
- SkyGuard SkyLine: Enhances operator protection by helping reduce the risk of entrapment incidents while working at height.
- Four-Wheel Hydrostatic Drive: Delivers excellent traction and manoeuvrability across rough terrain for improved site access and productivity.
- Oscillating Axle: Increases machine stability on uneven ground, giving operators greater confidence when travelling and positioning.
- 180 Degree Hydraulic Platform Rotator: Allows precise platform positioning, reducing the need to reposition the machine and improving efficiency.
- Proportional Controls: Provide smooth, accurate machine movements for safer operation and better control in confined or complex work areas.
- 5 Degree Tilt Alarm/Indicator Light: Alerts operators when the boom lift is operating on excessive slopes, supporting safer use and helping prevent instability.
Dual Fuel Engine
Deutz D2.9L4 Tier 4 Final: 49 hp, 36.4 kW
Fuel Tank Capacity: 83.3 L
Specs:
Platform Height 14.05 m
Working Height 16.05 m
Horizontal Outreach 12.23 m
Swing 360 Degrees Continuous
Platform Capacity (Restricted): 454 kg
Platform Capacity (Unrestricted): 300 kg
Platform Rotator: 180 Degrees Hydraulic Jib
Range of Articulation: 1.83 m
Weight: 8,736 kg
Max. Ground Bearing Pressure: 6.96 kg/cm²
Drive Speed: 6.8 km/h
Gradeability: 45%
Tilt Cut Out: 5 Degrees
Turning Radius (Outside): 4.8m
Turning Radius (Inside): 2.07m
The JLG “1 & 5” Warranty.
JLG Industries, Inc. backs its products with its exclusive “1 & 5” Warranty. We provide coverage on all products for one (1) full year and cover all specified major structural components for five (5) years.
Due to continuous product improvements, we reserve the right to make specification and/or equipment changes without prior notification.
This machine meets or exceeds AS/NZS 1418.10 2011 as originally manufactured for intended applications.
