Brian James DP27 Plant Trailer
$10,450.00 Inc. GST
$9,500.00 Ex. GST
The Brian James DP27 Plant Trailer is a smart, low-bed transport solution designed for heavy-duty plant machinery including tracked excavators, chippers, and shredders. Its robust build and low ride height make towing safer and more efficient, whether for large fleets or solo operators.
Part of the Digger Plant range from Brian James, the DP27 offers next-level towing performance with a focus on safety, load stability, and efficiency. Its cleverly engineered low ride height ensures optimal weight distribution, while the sturdy chassis and suspension make it a high-performance choice for professional users. Whether you’re transporting construction equipment or industrial machinery, the DP27 ensures fast, secure equipment movement at every turn.
Key Features
- The low ride-height design enhances towing stability by maintaining a lower centre of gravity.
- Its rugged chassis is rated for a gross weight of 2,700 kg and can carry 2,158 kg of equipment.
- Custom-fit trailer bed features a roomy 2.80 m load length and 1.30 m internal width.
- Measuring 4.65 m long and 1.79 m wide overall, it remains compact enough for varied site or road access.
- Equipped with a heavy-duty jockey wheel and locking tow hitch for safe manoeuvring.
- Built-in working load angle of 14° ensures alignment for seamless loading of machinery.
- Fits 13″ (165 6PR) tyres and utilises a twin-axle setup for improved load support and road compliance.
Towable via standard vehicle; no engine or external power required
Gross Trailer Weight (ATM): 2,700 kg
Load Capacity: 2,158 kg
Unladen Weight: 542 kg
Load Bed Length: 2.80 m
Internal Bed Width: 1.30 m
Overall Width: 1.79 m
Overall Length: 4.65 m
Bed Load Height: 0.38 m
Towball Height (Loaded): 0.40 m
Working Load Angle: 14°
Axle Count: 2
Tyre Specification: 13″ (165 6PR)
Comes with a 1-year standard manufacturer’s warranty. A 5‑year extended chassis warranty is available when the product is registered following purchase.
